The RSW™ - Auto Switching Redundancy System
The RSW™ is a cutting-edge redundancy solution for guitar and bass systems, designed to keep performances running without interruption. With a single button press, it seamlessly switches between primary and backup modellers while managing instrument signals, multipurpose jacks, line-level outputs, and MIDI data — ensuring preset changes stay perfectly synchronised.
Engineered for global use, the RSW™ supports universal input voltage and includes two high-quality 12V locking power supplies (3A each), eliminating the need for additional adapters. It also features IEC feedthroughs for powering mains devices, simplifying rig integration.
What truly sets the RSW™ apart is its auto-switching intelligence. If the primary modeller loses power or becomes unresponsive, the RSW™ instantly engages the backup — no manual intervention required.
By combining multiple functions into a single 1U rackmount unit, the RSW™ replaces the need for separate switchers and power supplies. This reduces cost, weight, and setup complexity, while its use of premium, readily available components ensures both sustainability and long-term serviceability.
By purchasing this product, you’re investing in more than just reliable performance—you’re supporting sustainable Scottish manufacturing. Each unit is designed, built, and tested locally, reducing transport emissions and keeping skilled jobs in our community. We prioritise high-quality, readily available components and responsible production methods, ensuring every piece of gear not only performs on stage but also contributes to a more sustainable future.
Power
Power input:
- 100-240VAC 50-60Hz IEC C14, 1500W Max, 130W Max if not using Mains Feedthroughs
Power output:
- IEC Feed Thru (Outlet F acc. to IEC 60320-3) x2
- 12VDC 2.1mm Centre Negative 3A x2
- Indicator LEDs for 12VDC outlets only
Audio
- Instrument/Line Input – TRS – Balanced (Max input 18dBU) – Impedance 1MΩ
XLR:
- Balanced Line (Max input 18dBU).
- Wiring: Pin 2/T = Hot, Pin 3/R = Cold, 1/S = Circuit Ground, Shell = Earth
- Ground lift switch disconnects Pin 1 of the output XLRs from the circuit ground
- Output Impedance 600Ω
Misc
Passive A/B
- TRS all connectors
- These are isolated from the rest of the circuit and passive, meaning they can each be used like a normal bidirectional A/B switcher e.g. 2 inputs (A/B) to 1 output (M) or 1 input (M) to 2 outputs (A/B), for FX Loops, Faslink™, Expression pedals, etc.
Size
Dimensions: 1U x 230mm deep (9”)
Weight: 2.3Kg (5.1lbs)
